Infrared thermometer STE-8-1-800
  • Infrared thermometer STE-8-1-800

Infrared thermometer STE-8-1-800

Infrared temperature measurement, self-supporting temperature control system, used for high-frequency, medium frequency induction heating equipment, electric heating equipment and other temperature measurement and control occasions

1. An upper/lower limit open-loop control (main control), 2. Backup temperature control port, upper limit temperature alarm, automatic work completion alarm, E multifunctional alarm, one external emergency stop port each, There are four optional multifunctional alarm modes, namely, upper limit alarm, upper limit alarm, lower limit reset, alarm between upper/lower limits, alarm above or below the upper limit, 3. The emissivity is adjustable, 4 STE-8-1 coaxial laser aiming STE-8-2 convergent laser aiming

Consult Now
customer service telephone numbers 400-900-8358

Power supply voltage: 220VAC, power consumption less than 10W


Distance coefficient: 75:1


◆ Probe cable length: 2.4M


◆ Repetition accuracy: 1℃


◆ Laser aiming: It can be switched on and off at will. If the laser aiming is enabled for 80 seconds and there is no operation on the laser aiming switch, it will automatically turn off after 80 seconds


◆ Digital emissivity adjustment


◆ Working environment temperature: Host ≤ 50 ℃ Humidity: 10% -80% Fiber optic probe: Temperature ≤ 50 ℃ Humidity: 10% -80%


◆ Appearance specifications: Host 175 (front and rear) × 240 (width) × 110mm (height) mm Probe diameter 45 × 120mm


Weight: Host: 3Kg+Probe holder: 1.3Kg+Local foot switch+Interface cable+Power cord=4.7Kg (approximately)
